Fajar Nickel Alloys is a reliable producer and supplier of high-quality Titanium Grade 11 Pipes, located in Jakarta, Indonesia. Known for their superior strength, resistance to corrosion, and hardness, these pipes are perfectly suitable for application in the aerospace, marine, and chemical processing sectors. Made of titanium alloyed with aluminum, vanadium, and palladium, they provide superior fatigue resistance and stability in high-temperature and high-pressure conditions. Regardless of deployment in harsh aircraft applications, seawater desalination, or corrosive chemical transportation, Titanium Gr 11 Pipes provide reliable performance. Fajar Nickel Alloys supplies custom-engineered solutions for specific industrial applications with guaranteed long-term reliability and optimum quality.
Titanium Grade 11 Pipes (UNS R56320 / DIN 3.7195) consist of around 3% aluminum, 2.5% vanadium, 0.25% palladium, and the remainder titanium, trace amounts of iron (maximum 0.25%) and oxygen (maximum 0.15%). All these alloying elements improve corrosion resistance and thermal performance. The pipes have a tensile strength of ~620 MPa, yield strength of 480 MPa, and elongation of 18%, which ensures great formability and fatigue strength. Having a density of 4.43 g/cm³, Titanium Gr 11 Pipes provide a very high strength-to-weight ratio and are perfect for structure and pressure-bearing environments in all critical sectors.
| Standards : | ASTM B862, B861 / ASME SB862, SB861 |
| Dimensional : | ANSI/ASME X6.19M, ANSI/ASME X6.10M |
| Seamless Pipe Size : | 1 / 2″ NB – 16″ NB |
| Welded Pipe Size : | 1 / 2″ NB – 24″ NB |
| Outside Diameter : | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock |
| Pipe Type : | Seamless / Welded / ERW / Fabricated / CDW / 100% X Ray Welded |
| Thickness Range : | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Pipes End : | Plain End, Beveled End, Treaded One End, TBE (Treaded Both Ends) |
| Value Added Services : | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Grade 11 | .08 max | .03 max | .25 max | .015 max | Bal | 0.30 max | – | .12 – .25 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.163 lb/in3 | 1668 °C | Psi – 39900 , MPa – 275 | Psi – 59500 , MPa – 410 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Grade 11 | 3.7195 | R56320 |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Grade 11 Pipes in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Grade 11 Tubes are much sought after in industries that need corrosion resistance, mechanical properties, and thermal stability. In the aerospace sector, they are applied to hydraulic systems, engine parts, and fuel pipes because of their high pressure and temperature endurance. The marine industry employs these tubes in shipbuilding, desalination plants, and offshore rigs because of their corrosion resistance to seawater. They are best suited for processing aggressive fluids and gases in chemical processing and petrochemical facilities. Moreover, they are biocompatible and, therefore, especially suitable for medical implants and devices to provide security and durable performance in health applications.
