Fajar Nickel Alloys, based in Jakarta, Indonesia, stands out as a reliable manufacturer and supplier of top-quality Titanium Tubing designed for tough industrial uses. With a strong focus on quality and engineering excellence, Fajar Nickel Alloys crafts titanium tubes that boast exceptional corrosion resistance, lightweight strength, and impressive durability even in extreme temperatures and pressures. The company offers both seamless and welded titanium tubing in a variety of grades and sizes, catering to sectors like aerospace, marine, chemical processing, medical, and power generation. Thanks to their precise manufacturing standards and attentive customer support, Fajar Nickel Alloys guarantees that their titanium tubing meets international performance and safety standards.
Fajar Nickel Alloys’ Titanium Tubing comes in both commercially pure grades (such as Grade 2) and alloyed grades (like Grade 5 – Ti-6Al-4V). Grade 2 is composed of about 98.9% titanium, with trace amounts of oxygen, iron, and other elements, providing excellent corrosion resistance and decent ductility. On the other hand, Grade 5 includes 6% aluminum and 4% vanadium, which enhances its strength and heat resistance. The mechanical properties vary, featuring tensile strengths from 350 to 950 MPa, yield strengths between 275 and 880 MPa, and elongation rates of 10 to 25%, depending on the grade. These tubes are not only highly formable and weldable but also perfect for high-stress, corrosive, or weight-sensitive applications.
| Standard | ASTM, AISI, GB, JIS, customers’ requests available |
| Size | Round Tube: OD: 16-119mm or customized |
| Thickness | 0.25mm-3.0mm |
| Length | 6m or according to customers’ request |
| Sample | Free sample is available, but freight should be paid by you |
| Tolerance | Outer diameter: ±0.2mm Thickness: ±0.05mm Length: ±0.5mm |
| Ends | In plain end or bevelled ends or as your requirements |
| Marking | Tubing are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
|---|---|
| Welding Line Type | ERW (Electrical Resistance Weld) |
| Finishing | A. Sanded B. Gloss #400,Mirror #600 – #1000 D. Wood Grain C. Brushed E. Embossed, Threaded |
| Form | ‘U’ bent, Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Etc |
| End | Plain End, Beveled End, Treaded Tube |
| Application | Decorations, constructions, food industry, etc. |
| Certification | ISO, SGS |
| Rectangle Pipe Size | 10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm |
| Thickness | exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Round Pipe Size | 16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm |
| Square Pipe Size | 17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm |
| Length | 6m or according to customer’s request |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc |
| Outer diameter | 6.35-219mm |
| Process method | Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished |
| Origin | West Europe / Japanese / Indian / USA / Korean / American / European |
| Test Certificates | Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Tubing in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Fajar Nickel Alloys’ Titanium Tubing finds its place in numerous industries where corrosion resistance, high strength, and lightweight materials are crucial. In aerospace, for instance, titanium tubing is utilized in hydraulic systems, fuel lines, and structural components. In the chemical processing sector, it’s the go-to choice for transporting corrosive fluids and gases. Marine applications include seawater piping, heat exchangers, and offshore structures. In the medical arena, titanium tubes are essential for implants and surgical instruments, showcasing their versatility and reliability across various fields.
