Fajar Nickel Alloys, located in Jakarta, Indonesia, stands out as a top-notch manufacturer and supplier of premium Titanium Tube Fittings. They cater to industries that require materials known for their corrosion resistance, lightweight strength, and long-lasting durability. With a focus on precision-engineered titanium products, Fajar Nickel Alloys provides tube fittings crafted from both commercially pure titanium (Grade 2) and titanium alloys (like Grade 5) to suit a variety of application needs. These fittings are built to perform reliably under high pressure and in harsh environments, making them perfect for sectors such as chemical processing, marine, aerospace, and medical. Fajar Nickel Alloys guarantees that each fitting meets international standards, ensuring consistent quality and performance across the globe.
When it comes to manufacturing Titanium Tube Fittings, the materials used are typically Grade 2 or Grade 5 titanium. Grade 2 is commercially pure titanium (about 99.2% Ti), known for its excellent corrosion resistance, weldability, and moderate strength (with a tensile strength of around 344 MPa). On the other hand, Grade 5 (Ti-6Al-4V) is a titanium alloy that includes 6% aluminum and 4% vanadium, offering higher strength (approximately 950 MPa tensile) along with good thermal and fatigue resistance. Both grades are lightweight, non-magnetic, and resistant to corrosion in various environments, including seawater and chemical exposure. The choice between the two grades depends on the specific mechanical and environmental requirements of the application.
| Specifications (ASTM/ASME) | ASTM B381/381M R56400, ASME SB381/381M R56400 |
| Tube Size | 1/16 OD to 2 OD, Od to 50mm OD |
| Types we Offer | Titanium Instrumentation Fittings Ti Grade 5 Double Ferrule Fittings Ti Grade 2 Twin Ferrule Fittings Ti-6al-4v Eli Titanium Ferrule Fittings Pure Titanium Pneumatic Fittings Ti Grade 6 Flare Fittings Cp Gr2 Ti JIC Fittings Tial6v4 Instrumentation Fittings Ti Alloys Grade 5 Hydraulic Hose Fittings ASTM B348 Grade 5 Compression Fittings Cp Grade 1 Double Ferrule Fittings ASME SB 348 Grade 2 Push-To-Connect Fittings Grade 5 Compression Fittings Ti Gr2 Hydraulic Fittings |
| Material Grades | Titanium Gr.5 – UNS R56400, Titanium Gr 2 – UNS R50400 |
| THREAD | BSPT, UNF, BSP, NPT, ISO, SAE, etc. |
| Forms | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Working Pressure | Upto 2000 to 6000 PSI |
| Medium – Pressure Gaugeable | Pressure Ratings: Up to 20 000 psig (1378 bar) Temperature Ratings: Up to 1000°F (537°C) |
| High-Pressure | Pressure Ratings: Up to 60 000 psig (4134 bar) Temperature Ratings: Up to 1000°F (537°C) |
| Body Type | FORGED, BAR STOCK |
| PTFE Standards | ASTM D1710, ASTM D3294 |
| Surface | Export bright finish, short blasted finish, electroplated finish |
| Applications Temperature | 150-400°C |
| Ends | Welding, Threaded, JIC |
| Packing Details | As per your detailed request Normally carton size – 21*16*14CM/31*21*16CM/36*45*50CM Normally wooden box size – 38*27*17CM Normally 1piece/ opp, 10-20pcs/ carton |
| Element | Ti | C | Fe | H | N | O | Al | V |
| Titanium | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Tube Fittings in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Tube Fittings find their place in numerous industries that demand exceptional corrosion resistance, high performance, and low weight. In the chemical and petrochemical sectors, they are essential for safely and reliably transporting corrosive fluids. The marine and offshore industries utilize them in seawater systems, desalination plants, and subsea equipment due to their outstanding resistance to saltwater. In aerospace, they play a crucial role in hydraulic and fuel systems where both strength and weight savings are vital. The medical and pharmaceutical fields appreciate titanium fittings for their biocompatibility and cleanliness.
