Fajar Nickel Alloys, located in Jakarta, Indonesia, has built a solid reputation as a reliable manufacturer and supplier of Titanium Grade 2 Tube Fittings. They cater to a variety of industries, delivering precision-engineered and corrosion-resistant solutions. Renowned for their outstanding quality and commitment to global standards, Fajar Nickel Alloys offers a dependable selection of Titanium Gr 2 tube fittings that are perfect for low to moderate pressure applications. These fittings are not only lightweight and incredibly durable but also excel in resisting both oxidizing and reducing environments. Commonly found in sectors like chemical processing, desalination, medical, and marine, Fajar Nickel Alloys guarantees consistent performance, longevity, and safety with every fitting they supply to clients both locally and internationally.
Titanium Grade 2 Tube Fittings are crafted from commercially pure titanium, which is about 99.2% titanium along with trace amounts of oxygen, iron, and other elements. This unique composition gives them remarkable corrosion resistance, especially in oxidizing and mildly reducing environments. On the mechanical side, Grade 2 titanium boasts a tensile strength of around 344 MPa, a yield strength of 275 MPa, and an elongation of about 20%. While it may not be as strong as Grade 5, it shines in terms of ductility, formability, and weldability. These characteristics make Titanium Gr 2 an excellent choice for applications that require a blend of strength, corrosion resistance, and ease of fabrication.
| Specifications | ASTM B366 / ASME SB366 |
|---|---|
| Size | 1/16 in. to 2 in. & 2mm to 50 mm. |
| Dimensional Range | 1/16 to 2 inches (imperial); 2 to 50 mm (metric) |
| Working Pressures | Upto 2000 to 6000 PSI |
| Thread Type | NPT – ASME B1.20.1, SAE AS71051 | ISO/BSP Parallel – ISO 228 | ISO/BSP Tapered – ISO 7, BS EN 10226-1 | SAE (Unified) – ASME B1.1 |
| End Connections | NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Max Working Pressure | 8MPa | 1200psi Depending on The Tubing Material |
| Working Temperature | -40°C—250°C | -40°F—482°F Depending on The Tubing Material |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Tube Fitting uses & application |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Grade 2 Tube Fittings in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Grade 2 Tube Fittings are extensively utilized in industries where lightweight and corrosion-resistant materials are crucial. In the chemical processing sector, they safely and efficiently manage corrosive fluids. In marine settings, they thrive in seawater applications, such as desalination plants and offshore structures. The medical field relies on them for surgical and implant-grade components due to their biocompatibility. Moreover, they find applications in heat exchangers, condensers, and power generation systems. Their formability and corrosion resistance make them a top choice for long-lasting, low-maintenance installations across various industries.
