Fajar Nickel Alloys, located in Jakarta, Indonesia, stands out as a top manufacturer and supplier of high-quality Titanium Ball Valves, specifically crafted for tough industrial applications. These valves are celebrated for their remarkable corrosion resistance, strength, and reliability, making them perfect for handling aggressive substances in sectors like chemical, marine, offshore, and pharmaceuticals. Available in various grades, including commercially pure Titanium Grade 2 and the more robust Grade 5 (Ti-6Al-4V), Fajar Nickel Alloys’ titanium ball valves ensure precise flow control, boast a long service life, and require minimal maintenance. With a commitment to engineering excellence and quality assurance, Fajar Nickel Alloys provides durable valve solutions for even the most extreme operating conditions.
Fajar Nickel Alloys’ Titanium Ball Valves are generally made from either Grade 2 or Grade 5 (Ti-6Al-4V) titanium. Grade 2 is about 98.9% pure titanium, known for its excellent corrosion resistance and weldability, while Grade 5, which includes 6% aluminum and 4% vanadium, offers enhanced strength (around 900 MPa tensile) and durability. These valves are lightweight, non-magnetic, and highly resistant to seawater, chlorides, acids, and high temperatures. Their strong mechanical properties and tight sealing capabilities make them perfect for high-pressure and high-purity applications, ensuring outstanding operational stability and chemical resistance in even the toughest environments.
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| STANDARD | ASTM B367, ASME B 16.10, BS EN 12266-1/API 598, ASME B 16.25, ASME B 16.5, BS1414/API 600, ASME B 16.34 |
| THREAD | BSPP, JIC, BSPT, METRIC, NPT, UNF |
| FUNCTION | 3 WAY, 2 WAY, 5 WAY, 4 WAY, |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| PRESSURE RATING | 3000 PSI, 15000 PSI, 6000 PSI, 1500 PSI, 10000 PSI, 20000 PSI |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| EQUIVALENT BRANDS | PARKER, OLIVER VALVES, SWAGELOK, HAMLET, DK-LOK, HOKE |
| SEAL RING MATERIAL | PVDF, PTFE, PEEK, DELRIN, GRAPHITE |
| MEDIA | AIR, HYDRAULIC OIL, GAS, WATER, HOT WATER , STEAM, SEA WATER , COLD WATER ,CHEMICAL |
| BODY TYPE | BAR STOCK |
| MEDIA TEMPERATURE | (-120* C – 500*C )RANGE AS PER PRESSURE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Ti | C | O | H | N | Fe | Al | V |
| Ti Grade5 | 90 min | – | 0.2 max | – | – | 0.25 max | 6 min | 4 min |
| Ti Grade2 | 99.2 min | 0.1 max | 0.25 max | 0.015 max | 0.03 max | 0.3 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Ball Valve in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Fajar Nickel Alloys’ Titanium Ball Valves are perfect for chemical processing plants, where they manage the flow of highly corrosive substances like acids, chlorides, and solvents. In marine and offshore settings, they are utilized in seawater systems, desalination processes, and ballast water treatment, thanks to titanium’s impressive resistance to saltwater corrosion. The aerospace industry also relies on them for hydraulic and fuel systems that demand a high strength-to-weight ratio. Additionally, the pharmaceutical and biotech sectors benefit from their reliability and performance in critical applications.
