Fajar Nickel Alloys, Jakarta, Indonesia, is a reliable manufacturer and supplier of high-quality Tantalum R05240 Sheets. With their unparalleled purity, superior corrosion resistance, and long-lasting durability in harsh conditions, these sheets find ideal applications in critical use in electronics, chemical processing, and aerospace industries. For exposure to aggressive chemicals as well as higher temperatures, Tantalum R05240 Sheets provide enduring, effective performance in even the most challenging situations. At Fajar Nickel Alloys, we adhere strictly to global quality standards, providing our customers with consistent, high-performance solutions designed specifically to satisfy the unique needs of their industrial applications.
Tantalum R05240 Sheets consist of high-purity tantalum designed for excellent corrosion resistance, particularly against aggressive acids such as hydrochloric and sulfuric acid. These sheets exhibit mechanical stability and structural integrity at high temperatures, possessing a melting point of around 2996°C. They display great thermal and electrical conductivity, which makes them suitable for use in high-precision applications. High ductility, biocompatibility, and chemical inertness enable the easy fabrication of these sheets with the assurance of long-term reliability. These properties make Tantalum R05240 Sheets useful for aggressive industrial conditions, medical application, and electronic systems that need absolute material integrity.
| Standard Specifications | ASTM B708, ASME SB708 / ASTM F 560 |
| Thickness | 0.5 mm – 30 mm |
| Width | 10mm – 2500mm |
| Length | As Your Required |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Types | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Purity | ≥99.9% or 99.95% |
| Grade | R05200, R05400, R05255, R05252, R05240 |
| C | O | N | H | Fe | Mo | Nb | Ni | Si | Ti | W | Ta |
| 0.010 | 0.015 | 0.010 | 0.0015 | 0.010 | 0.020 | 0.100 | 0.010 | 0.005 | 0.010 | 9.0 – 11.0 | Remainder |
| Dimension | Ultimate Tensile Strength, min, psi (MPa) | Yield Strength, min, psi (MPa) (2 % Offset) | Elongation, min, % |
| < 0.125″ (3.175mm) | 70000 (482) | 60000 (414) | 15 |
| ≥0.125″ (3.175mm) | 70000 (482) | 55000 (379) | 20 |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Tantalum R05240 Sheets and Plates in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Tantalum R05240 Sheets find extensive application in industries requiring high corrosion resistance, temperature stability, and purity of material. In the electronics industry, they find applications in producing capacitors, resistors, and semiconductor devices. In chemical processing, they are applied in reactors, vessels, and heat exchangers for highly corrosive materials. The aerospace industry uses them for withstanding high thermal and mechanical stress in flight-critical components. Owing to their biocompatibility, these sheets are also suitable for medical implants and surgical instruments, where safe long-term performance is critical in physiological conditions.
