Fajar Nickel Alloys, Jakarta, Indonesia, is a leading supplier and producer of pure-quality Tantalum R05200 Sheets. Their high purity, excellent corrosion resistance, and high performance at harsh conditions make the sheets best suited for high-stakes applications in electronics, chemical processing, and aerospace. Our Tantalum R05200 Sheets have unparalleled strength, chemical stability, and heat resistance, making them the best choice for harsh environments. With a high emphasis on quality, accuracy, and global compliance, Fajar Nickel Alloys is the reliable business associate for procuring high-performance tantalum materials for your specialized industrial applications.
Tantalum R05200 Sheets are fabricated from high-purity tantalum (≥99.95%), with superior chemical inertness and corrosion resistance, especially in acidic and aggressive conditions. The sheets have a melting point of 2996°C, good thermal and electrical conductivity, and retain mechanical strength at high temperatures. Its ductility and workability make easy fabrication into intricate shapes possible. Further, Tantalum R05200 is biocompatible, which makes it perfect for medical use. Having great dimensional stability and thermal stress resistance, these sheets ensure long-lasting performance under tough and high-precision environments.
| Standard Specifications | ASTM B708, ASME SB708 / ASTM F 560 |
| Thickness | 0.5 mm – 30 mm |
| Width | 10mm – 2500mm |
| Length | As Your Required |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Types | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Purity | ≥99.9% or 99.95% |
| Grade | R05200, R05400, R05255, R05252, R05240 |
| C | O | N | H | Fe | Mo | Nb | Ni | Si | Ti | W | Ta |
| 0.010 | 0.015 | 0.010 | 0.0015 | 0.010 | 0.020 | 0.100 | 0.010 | 0.005 | 0.010 | 9.0 – 11.0 | Remainder |
| Dimension | Ultimate Tensile Strength, min, psi (MPa) | Yield Strength, min, psi (MPa) (2 % Offset) | Elongation, min, % |
| < 0.125″ (3.175mm) | 70000 (482) | 60000 (414) | 15 |
| ≥0.125″ (3.175mm) | 70000 (482) | 55000 (379) | 20 |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Tantalum R05200 Sheets and Plates in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Tantalum R05200 Sheets find extensive use in applications that demand resistance to corrosion, thermal stability, and biocompatibility. For the electronics sector, they are necessary for the production of capacitors, semiconductors, and high-performance resistors. They are applied in chemical processing reactors, heat exchangers, and liners subjected to aggressive substances such as hydrochloric and sulfuric acids. Sheets from Tantalum have applications by the aerospace industry for components that can be exposed to extreme temperature and pressure. Tantalum R05200 Sheets, having biocompatibility, have applications in the medical field for implants and surgical instruments, which is used in dental applications, meaning sound performance without risks of wear and tear.
