Based in Jakarta, Indonesia, Fajar Metals is a top producer and supplier of Super Duplex Steel S32760 Wire. We offer high-performance wire solutions that satisfy the demands of demanding industries like desalination, chemical processing, offshore oil & gas, and marine. We are renowned for our accuracy and dedication to quality. Our Super Duplex S32760 Wire is renowned for its long service life in harsh conditions, outstanding strength, and superior resistance to corrosion. Fajar Metals is now a reliable partner for crucial wire applications in both domestic and foreign markets thanks to its sophisticated manufacturing capabilities, affordable prices, and quick delivery.
Approximately 25% chromium, 7% nickel, 3.5% molybdenum, and additions of tungsten, copper, and nitrogen are present in Super Duplex Steel S32760, a highly alloyed duplex stainless steel. This alloy exhibits exceptional resistance to stress corrosion cracking, pitting, and crevice corrosion. It has a yield strength of 550 MPa, a high tensile strength of about 750 MPa, and an elongation of about 25%. It has a balanced austenitic-ferritic microstructure that allows it to withstand corrosion and retain exceptional mechanical qualities even in harsh conditions like seawater, acidic media, and atmospheres high in chlorides.
| Size Range | 0.60 mm to 1.60 mm (0.025” to 0.062”) |
| Finish | Bright Finish, Matte Finish, Semi Bright/Matte Finish. |
| Diameter | 1/16″ (1.6 mm) |
| Materials | Super Duplex Steel |
| Product Type | Filler Wire |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32750 | 0.030 max | 1.20 max | 0.80 max | 0.035 max | 0.020 max | 24.00 – 26.00 | 3.00 – 5.00 | 6.00 – 8.00 | 0.24 – 0.32 | 58.095 min |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32750 / S32760 | 7.8 | 0.281 | 1350 | 2460 |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Steel Wire S32760 in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel S32760 Wire is widely used in applications that require exceptional strength, durability, and resistance to corrosion. Because of its ability to withstand corrosion from seawater, it is utilised in the offshore and marine industries for mooring cables, reinforcement, rigging, and safety lines. It is used in heat exchangers, pressure piping, and reactor vessels in the chemical and petrochemical industries. Additionally, it is utilised for wiring systems exposed to harsh chemicals in pulp and paper, mining, and desalination facilities. It is perfect for demanding structural and safety-critical industrial operations due to its high mechanical strength and corrosion resistance.
