Fajar Nickel Alloys stands out as a reliable manufacturer and supplier of top-notch Super Duplex Steel Needle Valves right from Jakarta, Indonesia. Designed for precise control in high-pressure and corrosive settings, our needle valves are crafted using advanced alloys like UNS S32750 and S32760. These valves find their place in offshore, petrochemical, chemical, and marine industries, where durability, leak-tight performance, and resistance to corrosion are essential. At Fajar Nickel Alloys, we ensure that every needle valve adheres to strict global standards such as ASTM, ASME, and NACE MR0175. With outstanding machining, impressive pressure ratings, and solid material integrity, our Super Duplex needle valves promise long-lasting, maintenance-free performance.
Super Duplex Needle Valves are crafted from alloys like UNS S32750 (F53) and UNS S32760 (F55), which include around 25% chromium, 7% nickel, 3.5% molybdenum, and 0.25% nitrogen. These components give the valves a high tensile strength of about 800 MPa, excellent yield strength of around 550 MPa, and remarkable resistance to corrosion, especially against pitting, crevice corrosion, and stress corrosion cracking in chloride-rich environments. The dual-phase microstructure also boosts fatigue resistance and stability against erosion under high-pressure conditions. These valves ensure precise flow control and long-term reliability, even in aggressive and dynamic processing systems.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Needle Valve in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel Needle Valves are extensively utilized for accurate fluid regulation in offshore oil and gas systems, chemical injection skids, desalination plants, and high-pressure instrumentation lines. In chemical and petrochemical facilities, they manage flow in systems that transport aggressive acids and chlorides. The marine sector uses these valves in ballast systems and environments prone to corrosion. Additionally, they find applications in power generation, hydraulic systems, and water treatment processes.
