Fajar Nickel Alloys is a leading producer of Super Duplex Manifold Valves, proudly established in Jakarta, Indonesia. Our valves are designed to provide exceptional performance, even under the most challenging conditions. Renowned for their superior corrosion resistance, high mechanical strength, and fatigue durability, these valves are perfectly suited to mission-critical applications in the oil and gas, chemical, and marine industries. Our Super Duplex Manifold Valves are designed to endure high internal pressures and hostile environmental conditions with utmost flow control and longer service life. At Fajar Nickel Alloys, we are committed to delivering superior quality, precision, and customer satisfaction with all our products.
Nitrogen, manganese, and the rest of the alloying elements of approximately 24–26% chromium, 6–8% nickel, and 3–5% molybdenum are used in the making of the Super Duplex Manifold Valves. This alloy is highly resistant to corrosion, especially in chloride-contaminated and acidic environments. The valves have high tensile strength (up to 800 MPa) and yield strength (approximately 550 MPa), as well as enhanced impact toughness and fatigue life. Their duplex microstructure is conducive to improved resistance to stress corrosion cracking, pitting, and crevice corrosion, making them last longer under harsh conditions. Moreover, they retain structural integrity under conditions of high pressure and temperature, thus well suited for harsh industrial uses.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Manifold Valve in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Manifold Valves are extensively applied to high–strength and heavily corrosive resistance industries. They are extremely important in offshore oil and gas production platforms, controlling fluid and gas flow under high pressure in marine environments. In chemical process plants, they are utilized to control aggressive and corrosive materials. These valves also serve a critical function in power generation and desalination plants, where stress corrosion cracking resistance and strength are required. Their longevity and capacity to deliver consistently under harsh conditions mean they are invaluable in mission-critical fluid control systems in different industries.
