Fajar Nickel Alloys is an established Jakarta-based manufacturer and supplier of high-grade steel and alloy materials. We specialize in producing Phosphor Bronze sheets and plates, designed for strength, durability, and excellent resistance to corrosion. Precise engineering and consistent quality make us well-known for delivering high-performance products serving diversified industries such as marine, construction, automotive, and electronics. With a emphasis on innovation and customer satisfaction, we provide solutions that conform to international standards and have reliability in challenging environments. Fajar Nickel Alloys strives to supply materials that have performance, longevity, and accuracy.
Phosphor Bronze sheets and plates are copper alloys with about 0.5–11% tin and 0.01–0.35% phosphorus. Tin strengthens, increases wear resistance, and corrosion resistance, while phosphorus enhances fatigue resistance, stiffness, and lowers friction. These characteristics provide Phosphor Bronze superior tensile strength, ductility, and dimensional stability. The alloy has better elasticity, machinability, and resistance to fatigue, which makes it suitable for high-performance applications. It can withstand heavy load and corrosive conditions, especially marine and industrial environments. These properties make it appropriate for accurate components in electrical, mechanical, and automotive applications.
| Material | Phosphor Bronze Sheet/Plate |
| Grade | Alloys 510, Alloys 521, Alloys 519, Alloys 544 |
| Standard | ASTM B103 |
| Size | Thickness 0.1 mm to 50 mm; Width up to 500 mm; Length up to 2000 mm |
| Surface | Rolling surface, Chemical cleaned, Grinding |
| Element | Zinc (Zn) | Iron (Fe) | Tin (Sn) | Copper (Cu) | Lead (Pb) | Phosphorous (P) | Nickel (Ni) | Others |
|---|---|---|---|---|---|---|---|---|
| % | .00 – .20 | .00 – .10 | 4.50 – 5.50 | Balance | .00 – .02 | .01 – .40 | .00 – .20 | .00 – .20 |
| Tensile strength | Hardness | Elongation at break | Modulus of elasticity | Izod impact strength | Shear strength |
|---|---|---|---|---|---|
| 320 – 740 MPa | Brinell : 80 – 225 | < 60 % | 90 – 120 GPa | 62 J m⁻¹ | 250 – 430 MPa |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Phosphorous Bronze Sheets and Plates in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Phosphor Bronze plates and sheets find extensive applications in industries that need materials with high corrosion resistance, wear resistance, and strength. They are suitable in the marine industry for bearings, bushings, and gears because they are seawater-resistant. In the electrical industry, they find applications in connectors, switches, and springs owing to their fatigue resistance and good conductance. They are employed in aerospace and automotive industries for diaphragms, fasteners, and precision parts requiring both dimensional accuracy and mechanical strength. They are also applicable to musical instruments, industrial machinery, and craft work due to their machinability.
