Home > Nickel Alloys > Nickel Alloys 200 Forged Fittings
Fajar Nickel Alloys, a prominent manufacturer and supplier from Jakarta, Indonesia, deals in Nickel Alloy 200 forged fittings designed for superior corrosion resistance, mechanical strength, and high thermal stability. Produced from high-purity Nickel 200, our forged fittings are suited for chemical processing, marine usage, and high-temperature applications. Our fittings are designed in accordance with international quality requirements to deliver superior performance under challenging conditions. With a high emphasis on precision engineering and durability, Fajar Nickel Alloys provides trusted, long-term solutions for industrial systems where performance and reliability are paramount. Count on us for top–quality components that get the job done when it counts.
| Dimension Specification | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
|---|---|
| Thread | NPT, BSPT, BSPP |
| Type | DN15-DN1200 |
| End | Threaded, Welding, JIC |
| Pressure Rating | Threaded end-2000lb/ 3000lb/ 6000lbs Pipe Fittings Socket-weld end-3000/ 6000/ 9000lbs Pipe Fittings |
| Connection | Welding |
| Manufacturing process | Push, Press, Forge, Cast, etc. |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Crosses, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows – Female-Female, Male-Female, Male-Male, Union, Nipples, Couplings, Plugs Fittings |
| Application |
|
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloys 200 Forged Fittings in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nickel Alloy 200 forgings fittings find extensive applications in petrochemical and chemical processing, food processing, and marine engineering because they are thermally stable and resistant to corrosive environments. They are best suited for parts of pipelines, heat exchangers, storage tanks, and reactors that frequently come into contact with caustic solutions, saline water, or high temperatures. The aerospace sector also employs these fittings in engine components and fuel systems because they are light, non-magnetic, and resistant to oxidation. They have a long lifespan, low maintenance requirements, and are resistant to thermal and mechanical stress, making them priceless in high-demand applications.
