Jakarta, Indonesia-based dependable producer and supplier Fajar Nickel Alloys provides first–rate Monel K500 Pipes, which are best known for the marvelous strength, corrosion resistance, and durability over an extended period. These pipes are designed to address the tough requirements of aerospace industries, oil & gas, chemical processing, and marine. All these pipes provide consistent performance in the most hostile conditions. With an intense emphasis on quality, innovation, and adherence to international standards, Fajar Nickel Alloys makes sure that every Monel K500 pipe is designed for maximum strength and working life. Let us be your source for strong and high-performance piping solutions that never sacrifice safety or dependability.
Monel K500 Pipes are constructed from a nickel-copper alloy consisting mainly of nickel (63–70%) and copper (27–33%), along with small amounts of aluminum (2.3–3.15%) and titanium (0.35–0.85%). These additions enable age hardening, further increasing the mechanical strength and hardness of the alloy. The pipes offer high tensile strength, superior corrosion resistance, and low magnetic permeability, making them suitable for sour gas applications and marine use. They also exhibit excellent resistance to stress-corrosion cracking, fatigue, and oxidation, retaining mechanical integrity in high-temperature and high-pressure conditions characteristic of challenging industrial environments.
| Specifications | ASTM B 163 ASME SB 163 / ASTM B 165 ASME SB 165 |
|---|---|
| Dimensions | ASTM, ASME and API |
| Size | 15″NB TO 150″NB IN |
| Specialized in | Large Diameter Size |
| Range | 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness. |
| Type | Seamless / ERW / Welded / Fabricated |
| Form | Round, Hydraulic Etc |
| Length | Single Random, Double Random & Cut Length. |
| End | Plain End, Beveled End, Treaded |
| Monel K500 | Ni | C | Al | Mn | Si | Fe | Cu | S | Ti | Cr |
|---|---|---|---|---|---|---|---|---|---|---|
| 63.0 min | 0.25 max | 2.3 – 3.15 | 1.5 max | 0.5 max | 05 – 2 | 27.0 – 33.0 | 0.010 max | 0.35 – 0.85 | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 1,60,000 , MPa – 1100 | 20 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel K500 Pipes Fittings in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel K500 Pipes find extensive applications in corrosive and harsh environments in various industries. They are most suitable in marine engineering for pump shafts, heat exchangers, and seawater system applications. In the oil and gas industry, they find applications in drilling tools, submersible pumps, and valve parts, with superior resistance in sour gas and high-pressure conditions. In chemical processing, Monel K500 Pipes are used in reactors, pipelines, and equipment that are exposed to acids and alkalis. Their toughness, strength, and resistance to corrosion make them ideal for use in the aerospace industry, such as fuel systems, hydraulic lines, and structure parts.
