Fajar Metals stands out as a leading manufacturer and supplier of top-notch Monel Forged Fittings, proudly based in Jakarta, Indonesia. Our Monel forged fittings are crafted for exceptional corrosion resistance and strength, making them perfect for tough applications in marine, chemical, and oil & gas sectors. Utilizing high-quality Monel alloys like Monel 400 and K500, these fittings are built to endure harsh environments, including seawater and acidic solutions. At Fajar Metals, we offer a diverse selection of forged fittings—such as elbows, tees, couplings, unions, and plugs—designed to meet international standards, ensuring reliability, safety, and longevity in critical systems.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel Forged Fittings in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel Forged Fittings find extensive use in systems that demand exceptional corrosion resistance, especially in marine, chemical processing, and oil & gas industries. They are perfect for seawater piping, offshore platforms, heat exchangers, chemical transfer lines, and hydrocarbon processing units. Thanks to their ability to handle acidic and alkaline conditions, they are also utilized in pump and valve assemblies, desalination plants, and fuel handling systems. These forged fittings guarantee secure, leak-proof connections, even under high pressure and temperature, and excel in chloride-rich or brine environments.
