Fajar Nickel Alloys is a leading producer and supplier of nickel alloy products with high performance, located in Jakarta, Indonesia. We are specialized in the production of Monel coils, specifically designed to withstand tough requirements of different industries. With outstanding corrosion resistance, high strength, and wear-resistant properties, our Monel coils are best suited for applications in extreme conditions. With an uncompromising focus on quality, innovation, and customer satisfaction, we offer customized solutions in line with global standards. For marine, chemical, or industrial uses, Fajar Nickel Alloys offers durable and efficient Monel coil solutions to complement the success of your operations.
Monel coils consist mostly of nickel (63–70%) and copper (28–34%), with small additions of iron, manganese, carbon, and silicon. This nickel-copper alloy possesses superior resistance to corrosion in seawater, acidic, and alkaline conditions. Monel has high tensile strength, superior thermal conductivity, and a melting point of approximately 1300°C. The alloy is resistant to stress corrosion cracking and retains its toughness and strength over a broad temperature range. Due to ease of fabrication and fair weldability, Monel coils are suitable for high-stress and high-performance services in aggressive industrial applications.
| Specifications | ASTM B127 / ASME SB 127, BS EN 10088-2, en 10028-7, IS 6911 |
| Dimensions | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range | Cold Rolled : 0.5-6.4 mm Hot Rolled : 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| International Standard of Sheets | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness | EN 10258/ DIN 59381 EN 10151 EN 10088 |
| Finish | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| C | Mn | Si | S | Cu | Fe | Ni | |
| Monel Coils | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
| Monel Coils | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel Coils in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel coils have extensive use in industries that demand strong materials with good performance in corrosive and high-temperature applications. In marine engineering, they find application in seawater piping, pump shafts, and heat exchangers because of their saltwater corrosion resistance. In chemical processing, Monel coils find use when they handle acidic and alkaline chemicals. The oil and gas industry depends on them for offshore drilling equipment, valves, and pressure vessels. Monel coils are employed by power generation and aerospace industries in turbine parts and high-temperature systems. Their corrosion resistance, strength, and durability make Monel coils necessary in high-demand and critical applications.
