Fajar Nickel Alloys is a renowned maker and distributor of high-performance Monel ball valves, with its corporate office located in Jakarta, Indonesia. Our Monel ball valves are designed to be highly durable, corrosion-resistant, and mechanically strong, making them suitable for demanding industrial applications. Constructed from top-quality nickel-copper alloy, the valves provide consistent flow regulation and extended service life even under severe temperatures and corrosive applications. Used extensively in the marine, aerospace, medical, and oil & gas sectors, our valves are of the highest international standards. Opt for Fajar Nickel Alloys for precisely engineered Monel ball valves that ensure exceptional performance and reliability.
Monel ball valves are usually produced from an alloy of about 63% nickel and 28–34% copper with small amounts of iron, manganese, carbon, and silicon. These valves provide superior corrosion resistance, particularly in seawater, acidic, and alkaline environments. Being highly resistant to tensile stress, with excellent toughness and thermal stability, they function flawlessly at higher temperatures. The oxidation, stress corrosion cracking, and pitting resistance of the alloy makes Monel ball valves the right option for critical applications where strength, tight sealing, and durability are crucial in adverse working conditions.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Ni | Mn | C | Si | Cu | S | Fe | Cr |
| Monel 400 | 63.00 min | 2.00 max | 0.30 max | 0.50 max | 28.0-34.0 | 0.24max | 2.50 max | – |
| Element | Melting Point | Yield Strength (0.2%Offset) | Elongation | Density | Tensile Strength |
| Monel 400 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | 40 % | 8.8 g/cm3 | Psi – 80,000 , MPa – 550 |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel Ball Valve in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel ball valves are extensively utilized by marine engineering, chemical processing, aerospace systems, and the oil and gas industry because of corrosion resistance and pressure reliability. When exposed to seawater for long periods of time in marine environments, they are not reduced in quality. They provide efficient and safe fluid control when they are exposed to acids, alkalies, and corrosive chemicals in the chemical and petrochemical processes. Aerospace and medical systems take advantage of their resilience, accuracy, and oxidation resistance. These valves are also employed in power generation plants and heat processing units, where smooth flow control and endurance are essential.
