Fajar Metals, based in Jakarta, Indonesia, has built a solid reputation as a manufacturer and supplier of precision alloy products, particularly Invar 36 Sheets and Plates. They’re well-known for their dedication to quality and technical excellence, providing dependable solutions for various industries, including aerospace, electronics, cryogenics, and precision engineering. Their Invar 36 Sheets and Plates are crafted to meet international standards, ensuring extremely low thermal expansion and outstanding dimensional stability. Fajar Metals caters to both local and international clients, delivering high-performance materials with consistent quality, prompt service, and tailored solutions for critical industrial needs.
Invar 36 Sheets and Plates consist of about 64% iron and 36% nickel, which gives them a uniquely low coefficient of thermal expansion. This alloy maintains remarkable dimensional stability from cryogenic temperatures all the way up to around 260°C. With a tensile strength between 490 and 620 MPa, it also showcases good toughness, ductility, and weldability. Notably, Invar 36 is magnetic at room temperature and excels in applications where precision and thermal stability are vital, making it ideal for both cryogenic and temperature-sensitive environments.
| Standards : | ASTM F1684 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc |
| Grade | C | Mn | Si | S | Co | Fe | Mo | Al |
| Invar 36 | .008 max | .30 max | .15 max | .001 max | .35 max | 63.0 max | .02 max | .03 max |
| Element | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Invar 36 | KSI (MPa) 63 / (430) Max | KSI (MPa)-38 / (260) Max | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Invar 36 | 1.3912 | K93600 | K93603 |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These Invar 36 Sheets and Plates find extensive use in the aerospace sector for satellite structures, optical devices, and precision instruments, where stability amid temperature fluctuations is essential. In the electronics and telecommunications fields, they’re utilized in components like CRT shadow masks, lead frames, and hybrid circuit packaging. Cryogenic applications include storage tanks and support structures for liquefied gases. Additionally, scientific and industrial sectors rely on Invar 36 for laser systems, measuring devices, and tooling fixtures that require precise dimensional control. Its unparalleled thermal stability makes it the go-to choice for critical, high-precision applications.
