At Fajar Nickel Alloys, we are proud to be a leading manufacturer and supplier of Inconel forged fittings in Jakarta, Indonesia. Driven by quality, precision, and performance, we ensure our fittings meet the most stringent industrial standards. Our Inconel forged fittings are developed to withstand high-temperature, high-pressure, and corrosive conditions and deliver long-term durability and operating reliability. Whether used in aerospace, pharmaceuticals, or marine systems, our products are engineered for optimal functionality. Fajar Nickel Alloys ensures every fitting is manufactured to international standards, making us a trusted name in the field of advanced alloy components.
Inconel forged fittings are typically made from Inconel 600 or 625, composed of nickel (58–72%), chromium (14–23%), iron, molybdenum, and trace elements like titanium and niobium. These fittings have high tensile strength, good fatigue resistance, and better heat-fatigue strength. Resistant to oxidation and corrosion above 1000°C, they are also resistant to chloride-ion stress corrosion cracking. Due to their very high thermal stability, mechanical strength, and weldability, Inconel forged fittings are perfectly suitable for harsh environments where pressure as well as temperature variations are routine.
| Specifications | ASTM B564 & ASME SB564 |
| Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Grades | Inconel 600, 601, 625, 718, 783, 690, X750 Forged Fittings |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Grade | Ni | C | Mn | Si | S | Cu | Fe | Cr |
| Inconel 600 | 72.00 min | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 14.00 – 17.00 |
| Inconel 601 | 58.0 – 63.0 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 21.0 – 25.0 |
| Inconel 625 | 58.0 min | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 20.0 – 23.0 |
| Inconel 718 | 50.00 – 55.00 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel Forged Fittings in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele
Contact us to get a quick quote for your requirement.
Inconel forged fittings find extensive application in high-temperature and high-pressure systems in several industrial sectors. They are used in jet engines, exhaust systems, and heat shields in the aerospace industry. They resist corrosive fluids and gases in chemical processing. They are depended upon by power generation plants for use in turbines, reactors, and boilers because they are stable under thermal stress. In the marine industry, they fight corrosion by saltwater and high humidity levels. Their durable design provides seal–tight connections, which can be applied to heat exchangers, gas turbines, and other applications wh
