Fajar Nickel Alloys is a leading manufacturer and supplier of high quality nickel alloy products based in Jakarta, Indonesia. We specialize in Inconel 625 stud bolts, known for exceptional strength and corrosion resistance. Designed to operate in harsh environments, these stud bolts are ideal for demanding applications in the aerospace, marine and medical industries. Committed to providing high quality products and excellent customer service, Fajar Nickel Alloys ensures that every Inconel 625 stud bolt meets the exacting standards of durability and performance.
Inconel 625 stud bolts are manufactured from 58% nickel, 22-24% chromium and 8-10% molybdenum to provide resistance to oxidation, corrosion and high temperature Mechanical properties 827 MPa tensile strength, 655 MPa yield strength and 30% elongation , respectively Maintained strength and durability Benefits of Inconel 625 stud bolts include excellent resistance to seawater, acidic and tropical environments, making them ideal for aerospace, marine and chemical applications work Their strength and corrosion resistance ensure long-term reliability in harsh conditions.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 625 Stud Bolts in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 625 stud bolts are widely used in high-pressure, high-temperature, and corrosive environments. They are ideal for aerospace applications, where they can withstand extreme temperatures and mechanical stresses. In the marine industry, these stud bolts are corrosion resistant to seawater, providing durability under harsh conditions. It is used in chemical processing and power generation, where its resistance to oxidizing and reducing environmental factors improves its performance. In addition, Inconel 625 stud bolts are used in cryogenic applications due to their low thermal conductivity and flexibility, providing reliable performance in demanding environments.
