Fajar Metals, a trusted manufacturer and supplier located in Jakarta, Indonesia, specializes in high-quality Inconel 625 Forged Fittings designed for tough industrial settings. Crafted from Inconel 625, a nickel-chromium-molybdenum alloy celebrated for its remarkable corrosion resistance and strength, these forged fittings are perfect for a variety of high-temperature and corrosive applications. Adhering to international standards like ASTM B564 and ASME B16.11, Fajar Metals provides socket weld and threaded forged fittings in various classes, including 3000#, 6000#, and 9000#. These fittings are particularly suited for industries such as chemical processing, marine, aerospace, and offshore oil & gas.
Inconel 625 Forged Fittings are mainly made up of Nickel (at least 58%) and Chromium (around 21.5%), along with notable amounts of Molybdenum (approximately 9%), Iron, and Niobium. These components give the alloy its exceptional resistance to oxidation, pitting, crevice corrosion, and stress-corrosion cracking. In terms of mechanical properties, Inconel 625 boasts a tensile strength of about 827 MPa, yield strength of roughly 414 MPa, and impressive elongation of around 30%, even at temperatures ranging from cryogenic levels to 982°C. The forged fittings also demonstrate excellent weldability and toughness, making them ideal for connections in pressure-bearing and corrosive systems.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 625 Forged Fittings in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 625 Forged Fittings are widely used in applications requiring high strength, corrosion resistance and durability. They excel in harsh environments, making them ideal for applications in the chemical industry, aerospace, marine and power generation. These inserts are particularly useful in pipeline systems exposed to extreme temperatures and corrosive elements, providing reliable long-term service Their versatility also makes it suitable for oil and gas extraction, where resistance to high pressure and seawater corrosion is required.
