Fajar Nickel Alloys, a premier manufacturer and supplier in Jakarta, Indonesia, specializes in providing top-grade Inconel 617 nuts. These nuts are known for their exceptional resistance to oxidation, corrosion, and high-temperature environments, making them ideal for various industrial applications. Fajar Nickel Alloys ensures the highest quality standards, delivering durable and reliable Inconel 617 nuts that meet the demanding requirements of clients worldwide. With a strong commitment to excellence, they are a trusted partner for all your Inconel fastener needs.
Inconel 617 nuts are made from a nickel-chromium-cobalt-molybdenum alloy, which offers excellent oxidation resistance and high strength Contains about 20-24% chromium, 10-15% cobalt and 8-10% molybdenum. These nuts have a tensile strength of 827 MPa and a yield strength of 414 MPa. Their high breaking strength, oxidation resistance, and high temperature carburization make them ideal for use in gas turbine, chemical, and nuclear reactors Furthermore, Inconel 617 nuts are very durable, and provide it works for long periods of time in dangerous environments.
Standard ASTM F467, ASTM B564, B166 / ASME SF467, ASME SB564, SB166
Dimensions ANSI B18.2.2, DIN 934,ISO 4032, BS1768, BS 1769
Threads Configuration ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads
Size M02 to M160
Type Cold Forged, Hot Forged, Bar Stock Machined, Bar Stock Milling
Length 3 mm to 200 mm
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 617 Nuts in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 617 nuts is widely used in applications requiring high temperature and oxidation resistance. Its excellent creep and rupture strength and oxidation resistance make it ideal for gas turbine combustion cans and transition liners. It is used in industrial furnaces, fuel cells, and heating appliances, where it is often exposed to extreme temperatures. In addition, because of its stability under extreme conditions, Inconel 617 nuts has been used in nuclear reactors and power plants. Its versatility and durability make it an essential component in complex applications.
