Fajar Nickel Alloys is a reliable manufacturer and supplier of Inconel 601 Stud Bolts, proudly based in Jakarta, Indonesia. We specialize in delivering high-performance fasteners that can handle extreme temperatures, corrosive environments, and thermal cycling with ease. Crafted from a nickel-chromium alloy with aluminum additions, our Inconel 601 stud bolts are perfect for industries like aerospace, petrochemical, heat treatment, and power generation. Built to meet international standards such as ASTM B166, these stud bolts boast impressive dimensional accuracy, mechanical strength, and durability, making them ideal for both local and global industrial applications.
Inconel 601 Stud Bolts consist of nickel (≥58%), chromium (21–25%), and aluminum (1–1.7%), providing exceptional resistance to high-temperature oxidation, scaling, and carburization. They maintain their strength and integrity even at temperatures up to 1200°C (2200°F) and excel in both oxidizing and sulfur-rich environments. Their remarkable resistance to stress corrosion cracking, along with solid mechanical properties, ensures they are dependable for critical fastening in tough service conditions.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Stud Bolts in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These bolts are commonly found in high-temperature and corrosive settings, such as heat exchangers, industrial furnaces, reactors, exhaust systems, and gas turbines. They’re also utilized in chemical processing equipment and thermal oxidizers, where resistance to oxidation and thermal fatigue is essential. With their ability to provide secure and stable fastening in environments exposed to extreme heat, vibration, and aggressive chemicals, Inconel 601 stud bolts are the go-to choice for safety-critical and high-performance industrial installations.
