Fajar Metals, a well-respected manufacturer and supplier located in Jakarta, Indonesia, specializes in providing top-notch Inconel 600 Sheets and Plates designed for tough industrial applications. Crafted from a nickel-chromium-iron alloy, these sheets and plates boast exceptional resistance to heat, oxidation, and corrosive environments. They are produced in line with ASTM B168 standards and come in a variety of thicknesses, widths, and lengths to meet different application needs. Inconel 600 sheets and plates are perfect for use in chemical processing, thermal processing, aerospace, and nuclear power plants, delivering impressive mechanical strength and corrosion resistance even in the harshest conditions.
| 600 Sheets & Plates Specifications | ASTM B168 / ASME SB168, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 600 Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Alloys 600 Sheets & Plates Size Range | Cold rolled ASME SB168 Grade 600 Inconel Sheet 0.5-6.4 mm Hot rolled ASME SB168 Grade 600 Inconel Sheet 3.0–10.0 mm |
| 600 Inconel Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Inconel 600 Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Inconel 600 Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Inconel 600 Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Inconel 600 Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SB168 600 Inconel Strips EN 10088 SA -240-600 Strips |
| Finish of Inconel 600 Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Inconel 600 Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 600 Sheets and Plates in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 600 sheets and plates are used in a range of high-temperature and corrosive applications. They are essential in chemical processing for handling aggressive fluids, in heat exchangers for their resistance to oxidation, and in furnace components for their durability under extreme heat. Additionally, they are utilized in aerospace for engine components and in various industrial processes where high strength and resistance to corrosion are crucial. Their versatility and performance make them suitable for demanding environments.
