Fajar Metals, located in Jakarta, Indonesia, stands out as a trusted manufacturer and supplier of high-quality Incoloy Valves, designed to provide robust flow control solutions even in the toughest operating conditions. Renowned for their durability, resistance to corrosion, and ability to withstand high temperatures, Fajar Metals’ Incoloy Valves are crafted to comply with international industry standards. These valves excel in handling aggressive media across various sectors, including chemical processing, oil and gas, marine, and power generation. With state-of-the-art production facilities and rigorous quality checks, Fajar Metals guarantees exceptional performance and longevity, proudly serving clients throughout Indonesia and Southeast Asia with reliable alloy valve solutions.
Incoloy Valves are crafted from nickel-iron-chromium alloys, often enhanced with molybdenum, copper, and titanium, depending on the specific grade, like Incoloy 800 or 825. These materials offer remarkable resistance to corrosion, oxidation, and stress-cracking, even in acidic and high-temperature settings. Typical mechanical properties include a tensile strength ranging from 500 to 750 MPa, yield strength between 200 and 450 MPa, and elongation of 30 to 45%. Incoloy Valves maintain their mechanical integrity across a broad temperature spectrum and boast excellent weldability and workability. Their unique composition allows for custom valve configurations, making them ideal for demanding industrial applications involving aggressive fluids and gases.
| Material | Incoloy |
|---|---|
| Seal Material | PTFE/ RPTFE |
| Working Pressure | 1.6 – 6.4Mpa |
| Working Temperature | -29°C — +180°C |
| Availabe Size | 1/2″-4″,(DN15-DN100) |
| Available Connection | BSP/ BSPT/ NPT/ Flanged/ Welded |
| Nominal Pressure | P10/PN16 |
| Operation | Manual,Pneumatic, Electric |
| Suitable Medium | Water,Sewage,Seawater,Gas,Food,Oils,etc |
| Standards | GB9112,DIN2501,BS4504,ISO2084,ANSI125 |
| Applications | Water, Oil, Gas, |
| Nominal Diameter | DN40-DN300 handle lever DN350-DN1200 gear box |
| Operation Temperature | -10°C~150°C |
| Grade | Ni | Fe | Cr | Cu | Mn | S | Si | Ti | Al | C |
| Alloys 800 | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .15-.60 | .15-.60 | .1 max |
| Alloys 800HT | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .25-.60 | .85-1.20 | .06-.10 max |
| Alloys 800H | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .15-.60 | .15-.60 | .05-.10 max |
| Density | Yield Strength (0.2%Offset) | Melting Point | Tensile Strength | Elongation |
| 7.94 g/cm3 | Psi – 30,000 , MPa – 205 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | 30 – 35 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Valve in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy Valves find extensive use in industrial systems where resistance to corrosion, pressure, and heat is essential. In the chemical and petrochemical sectors, they are utilized in acid-handling systems, heat exchangers, and high-pressure flow control applications. The oil and gas industry employs them in offshore platforms, sour gas processing, and refinery systems. In power generation, these valves are crucial for steam and condensate lines. The marine industry also relies on Incoloy Valves for their durability and performance in challenging environments.
