Fajar Metals, a prominent manufacturer and supplier based in Jakarta, Indonesia, specializes in high-quality Incoloy 825 Pipe Fittings that are engineered to excel in harsh, corrosive, and high-temperature settings. These fittings are made from a robust nickel-iron-chromium alloy, enhanced with molybdenum, copper, and titanium, making them perfect for handling aggressive chemicals and seawater. Produced in line with international standards like ASTM B366, Incoloy 825 pipe fittings boast impressive mechanical strength, corrosion resistance, and durability. They are widely used in chemical processing, oil and gas facilities, marine systems, and pollution control units, ensuring dependable and leak-proof piping connections in critical applications.
Incoloy 825 Pipe Fittings are composed of Nickel (38–46%), Iron (the balance), Chromium (19.5–23.5%), Molybdenum (2.5–3.5%), Copper (1.5–3%), and Titanium (0.6–1.2%). This well-balanced composition grants them remarkable resistance to both oxidizing and reducing acids, particularly sulfuric and phosphoric acids. The fittings showcase a tensile strength of 585 MPa, a yield strength of 220 MPa, and an elongation of about 30%. Their outstanding resistance to intergranular attack, pitting, and stress corrosion cracking makes them ideal for high-stress industrial piping systems that face severe conditions.
Specifications : ASTM B366 / ASME SB366
Size : Seamless Inconel / Incoloy Butt Weld Fittings: 1/2″ – 10″
Welded Inconel / Incoloy Butt Weld Fittings: 1/2″ – 48″
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Thickness : SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Types : Seamless / Welded / Fabricated
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Inconel Pipe Fittings | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel Pipe Fittings | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 825 Pipe Fittings in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 825 Pipe Fittings are used in a variety of demanding applications due to their excellent corrosion and high-temperature resistance. They are ideal for chemical processing industries, where they handle corrosive substances and high pressures. In the oil and gas sector, these fittings manage aggressive environments and extreme conditions. They are also employed in marine applications to resist seawater corrosion and in pollution control systems for flue gas desulfurization, ensuring durability and reliability across diverse settings.
