Fajar Metals, a well-respected manufacturer and supplier based in Jakarta, Indonesia, specializes in high-quality Incoloy 825 Pipes that are celebrated for their exceptional corrosion resistance and mechanical properties. Crafted from a top-notch nickel-iron-chromium alloy, these pipes also include molybdenum, copper, and titanium, which significantly boost their ability to endure both oxidizing and reducing environments. Meeting international standards like ASTM B423, Incoloy 825 pipes are perfect for demanding chemical services, high-temperature applications, and marine settings. Industries such as chemical processing, oil & gas, power generation, and marine engineering rely on these pipes for their durability and resistance to pitting and crevice corrosion.
Incoloy 825 Pipes are composed of Nickel (38–46%), Iron (the balance), Chromium (19.5–23.5%), Molybdenum (2.5–3.5%), Copper (1.5–3%), and Titanium (0.6–1.2%). This unique alloy mix offers remarkable resistance to sulfuric and phosphoric acids, along with protection against stress corrosion cracking and intergranular attack. With a tensile strength of about 585 MPa, yield strength of 220 MPa, and an elongation of 30%, these pipes are perfectly suited for applications that require both corrosion resistance and structural integrity, especially in high-pressure or high-temperature situations.
Specifications : ASTM B423, B705, B704 / ASME SB423, SB705, SB704
Standard : ASTM, ASME and API
Size : 15″NB – 150″NB
Outer Diameter : 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness.
Length : Single Random, Double Random & Cut Length
Schedule : SCH 10, SCH20, SCH30, SCH50, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS
Types : Seamless / ERW / Welded / EFW / Fabricated / CDW
| Grade | C | Al | Ti | S | Cu | Fe | Ni |
| Incoloy 825 Pipe | 0.05 max | 0.2 max | 0.6 – 1.2 | 0.03 max | 1.5 – 3.0 | 22.0 min | 38.0 – 46.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy 825 Pipe | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 825 Pipes in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 825 Pipes are used in various demanding industrial applications due to their excellent corrosion and oxidation resistance. They are ideal for chemical processing industries, where they handle corrosive acids and alkalis. In oil and gas sectors, these pipes manage high-pressure and corrosive environments. Additionally, they are employed in marine applications to withstand seawater corrosion and in pollution control systems for flue gas desulfurization. Their durability makes them suitable for high-performance, high-stress applications across multiple industries.
