Fajar Metals, a reputable manufacturer and supplier located in Jakarta, Indonesia, specializes in high-performance Incoloy 825 Forged Fittings that are crafted for exceptional corrosion resistance and strength in tough environments. These fittings are made from a unique nickel-iron-chromium alloy, enhanced with molybdenum, copper, and titanium, making them resilient against both oxidizing and reducing conditions. Produced in line with international standards like ASTM B564, they find extensive applications in chemical processing, power generation, oil and gas, and marine industries. Their remarkable resistance to stress corrosion cracking and general corrosion makes them perfect for secure and durable pipe connections in demanding situations.
Incoloy 825 Forged Fittings are composed of Nickel (38–46%), Iron (the balance), Chromium (19.5–23.5%), Molybdenum (2.5–3.5%), Copper (1.5–3%), and Titanium (0.6–1.2%). This alloy is known for its exceptional resistance to acid corrosion, particularly against sulfuric and phosphoric acids, as well as its ability to withstand chloride stress corrosion cracking. Typically, these fittings boast a tensile strength of 585 MPa, a yield strength of 220 MPa, and an elongation of around 30%, ensuring reliable mechanical integrity under pressure and during thermal cycling in corrosive environments.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Incoloy 800, 800H, 800HT, 825, 925 Forged Fittings
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy Forged Fittings | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy Forged Fittings | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 825 Forged Fittings in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele
Contact us to get a quick quote for your requirement.
Incoloy 825 Forged Fittings are extensively used in industries requiring superior corrosion resistance, such as chemical processing, oil and gas, and marine applications. They are ideal for handling aggressive chemicals, acids, and seawater, ensuring reliable performance in harsh environments. These fittings are commonly utilized in piping systems, heat exchangers, and pressure vessels where high resistance to pitting and crevice corrosion is critical. Incoloy 825 Forged Fittings provide long-lasting durability and safety, making them essential in demanding industrial operations.
