Fajar Metals stands out as a trusted manufacturer and supplier of high-performance Haynes 230 Sheets and Plates, proudly based in Jakarta, Indonesia. Crafted for exceptional strength and oxidation resistance at high temperatures, Haynes 230 is a nickel-chromium-tungsten-molybdenum alloy that thrives in extreme thermal conditions. Our sheets and plates are meticulously precision-rolled and rigorously quality-tested to meet the demanding standards of industries like aerospace, power generation, heat treating, and chemical processing. At Fajar Metals, we provide Haynes 230 products in a variety of thicknesses, widths, and lengths, ensuring reliable performance and a long service life in high-temperature, high-stress environments.
| Specification : | AMS 5878 |
| Standard : | AMS, AMS, API |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Size : | 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Haynes 230 (UNS N06230) |
| Weight% | C | Mn | Si | P | S | Cr | Co | Fe | Al | Ti | B | Cu | La | W | Mo | Ni |
| Haynes 230 | 0.05-0.15 | 0.30-1.0 | 0.25-0.75 | 0.03 | 0.015 | 20.0-24.0 | 5.0 | 3.0 | 0.20-0.50 | 0.10 | 0.015 | 0.50 | 0.005-0.05 | 13.0-15.0 | 1.0-3.0 | Rem |
| Material | Test Temp °F | Ultimate Tensile Strength | 0.2 % Yield Strength | Elongation in % | Hardness HB |
| Haynes Alloys 230 Extruded Bar Solution Treated (AMS 5891) | RT | 758 Mpa 110 ksi | 310 Mpa 45 ksi | 35 | 241 max |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Sheets and Plates in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Haynes 230 Sheets and Plates find extensive use in high-temperature structural components like combustion liners, transition ducts, and turbine seals in gas turbines and aerospace engines. In the power generation sector, they are utilized in heat exchangers, boiler linings, and coal gasification systems. The chemical processing industry benefits from their resistance to oxidizing and nitriding environments in reactors, furnace retorts, and thermal oxidizers. Their weldability and thermal stability also make them ideal for industrial furnaces, kilns, and exhaust handling systems.
