Fajar Metals stands out as a reliable manufacturer and supplier of high-performance alloy products right in Jakarta, Indonesia. We offer a diverse selection of industrial components, including our top-notch Hastelloy Flanges. Renowned for their precision engineering and exceptional corrosion resistance, these flanges are crafted to meet the demanding needs of industries like chemical processing, marine, and power generation. With a strong focus on quality, innovation, and customer satisfaction, Fajar Metals employs advanced manufacturing techniques and adheres to international standards, ensuring that our durable and dependable flanges are ready for both local and global markets. Our dedicated team is committed to timely delivery and providing technical support to cater to various industrial applications.
| Specifications | Hastelloy Flanges |
|---|---|
| ASME B16.5 Hastelloy C276 Flange size range | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Hastelloy Flanges Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flanges. |
| Hastelloy C276 Flange Standard ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Hastelloy C276 Flange Standard DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| Hastelloy C276 Flange Standard JIS | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
| Hastelloy C276 Flange Standard UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Hastelloy C276 Flange Standard EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Main Types | Forged / Threaded / Screwed / Plate |
| Flange supporting material | Gasket, Ring Joint, Flange Bolts |
| Hastelloy C276 Pipe Flanges Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Most common types of Hastelloy C276 Flanges |
|
| Production technique |
|
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS 15 NB (1/2″) to 200 NB (8″) Equal and Reducing Configurations Hastelloy C276 Threaded Flange, Socketweld Flange, Slip-On Flange, Blind Flange, Weld Neck Flange |
| Grade | Hastelloy C22 |
|---|---|
| C | 0.010 max |
| Mn | 0.50 max |
| Si | 0.08 max |
| S | 0.02 max |
| Co | 2.50 max |
| Ni | 50.015 min |
| Cr | 20.00 – 22.50 |
| Fe | 2.00 – 6.00 |
| Mo | 12.50 – 14.50 |
| P | 0.02 max |
| Density | 8.89 g/cm3 |
| Melting Point | 1370 °C (2500 °F) |
| Tensile Strength | Psi – 1,15,000 , MPa – 790 |
| Yield Strength (0.2%Offset) | Psi – 52000 , MPa – 355 |
| Elongation | 40 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Flanges in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy Flanges find extensive applications in chemical processing, aerospace, marine engineering, power plants, and pharmaceutical manufacturing, thanks to their superior corrosion resistance and mechanical strength. They are particularly well-suited for harsh environments that involve strong acids, chlorides, and elevated temperatures, making them perfect for heat exchangers, reactors, pressure vessels, and pipe connections in corrosive systems. In the marine sector, they play a crucial role in preventing corrosion caused by saltwater and biofouling. Fajar Metals provides Hastelloy Flanges in various configurations to meet the specific needs of our clients.
