Fajar Metals, a well-respected manufacturer and supplier located in Jakarta, Indonesia, specializes in top-notch Hastelloy C276 Stud Bolts that are built for outstanding durability and resistance in harsh, high-temperature environments. These stud bolts are perfect for critical applications across various industries, including chemical processing, oil and gas, pharmaceuticals, and power generation. Renowned for their remarkable strength and precise threading, Fajar Metals’ Hastelloy C276 Stud Bolts are crafted to meet international standards, ensuring secure and long-lasting fastening even in the toughest conditions. With a strong emphasis on quality and performance, Fajar Metals provides reliable stud bolts tailored to meet the rigorous demands of industrial specifications.
| Specification | ASTM F468, B574 / ASME SF468, SB574 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| Hastelloy C22 Stud Bolts | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy C22 Stud Bolts in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy C22 stud bolts are widely used in industries requiring exceptional corrosion resistance and durability. They are ideal for chemical processing, oil and gas, and power generation, where exposure to harsh chemicals, acids, and high temperatures is common. These bolts are used in heat exchangers, reactors, valves, and piping systems, particularly in environments prone to pitting and stress corrosion. Their versatility and reliability make them essential in ensuring secure, long-lasting connections in the most demanding applications.
