Fajar Metals stands out as a reliable manufacturer and supplier of top-notch metal-based industrial components right in the heart of Jakarta, Indonesia. With a focus on corrosion-resistant alloys and high-performance equipment, they provide cutting-edge flow control solutions, including their renowned Hastelloy Ball Valves. These valves are specifically designed to endure harsh chemical environments, making them perfect for demanding sectors like chemical processing, marine, pharmaceuticals, and energy. Committed to quality assurance, precision machining, and following international standards, Fajar Metals guarantees that their Hastelloy Ball Valves cater to both local and global market demands. Plus, their strategic location in Jakarta ensures smooth logistics and dependable customer service.
Hastelloy Ball Valves from Fajar Metals are generally crafted from Hastelloy C-276 or C-22, primarily consisting of nickel (around 57%), along with notable amounts of molybdenum (15–17%), chromium (14.5–16%), iron (about 5%), and trace elements like cobalt and tungsten. These alloys are known for their outstanding resistance to pitting, stress corrosion cracking, and oxidizing agents. In terms of mechanical properties, they boast a tensile strength of approximately 760 MPa, a yield strength of 283 MPa, and an elongation of around 40%. Even in extreme temperatures and corrosive settings, these valves maintain their strength and ductility, adhering to ASTM B622 and NACE standards.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | C | Co | S | Si | Cr | Ni | Mo | Fe | W |
| Alloys C22 | 0.50 max | 0.010 max | 2.5 max | 0.02 max | 0.08 max | 20 – 22.5 | Bal | 12.5 – 14.5 | 2 – 6 | 2.5 – 3.5 |
| Alloys C276 | 1.0 max | 0.010 max | 2.5 max | 0.03 max | 0.08 max | 14.5 – 16.5 | Bal | 15 – 17 | 4 – 7 | 3 – 4.5 |
| Element | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength | Elongation |
| Alloys C22 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | 8.69 g/cm3 | Psi – 1,00,000 , MPa – 690 | 45 % |
| Alloys C276 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 40 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Ball Valve in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Fajar Metals’ Hastelloy Ball Valves find extensive application in tough environments where corrosion resistance is a must. They are particularly suited for chemical processing plants that deal with strong acids such as hydrochloric, sulfuric, and nitric acid. Additionally, these valves are utilized in marine settings, pharmaceutical production, pulp and paper industries, and wastewater treatment facilities. Thanks to their durability under high pressure and temperature, they are also ideal for offshore oil and gas operations. With their smooth operation and leak-proof design, they truly excel in demanding applications.
