Home > Duplex Steel > Duplex Steel Sheet and Plates
Fajar Metals, a reputable manufacturer and supplier located in Jakarta, Indonesia, provides an extensive selection of high-quality metal products, including Duplex Steel Sheets and Plates. Renowned for their remarkable mechanical strength and exceptional corrosion resistance, these sheets and plates are designed to excel in the most demanding environments. With cutting-edge production methods and rigorous quality control, Fajar Metals guarantees that every product adheres to international standards like ASTM, ASME, and EN. Catering to sectors such as oil & gas, chemical processing, marine, and construction, Fajar Metals offers robust and high-performance duplex steel solutions for both local and global markets.
| Specifications | ASTM A240 / ASME SA 240 |
| Duplex Steel Plate Grades | 2205, 2507 |
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Width | 10-2500mm |
| Length | 2m,2.44m, 3m as per requirement |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Cold rolled sheet (CR), Hot rolled plate (HR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| MN | C | SI | S | P | CR | NI | MO | N |
|---|---|---|---|---|---|---|---|---|
| 2.0 max | 0.03 max | 1.0 max | 0.02 max | 0.03 max | min: 21.0 max: 23.0 | min: 4.5 max: 6.5 | min: 2.5 max: 3.5 | min: 0.08 max: 0.20 |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Sheets and Plates in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Fajar Metals’ Duplex Steel Sheets and Plates find extensive use in applications that demand strength, corrosion resistance, and longevity. In the oil and gas industry, they are essential for offshore platforms, pipelines, and storage tanks. In the chemical and petrochemical sectors, they are utilized in pressure vessels, heat exchangers, and reactors. The marine industry relies on them for shipbuilding and desalination plants due to their excellent resistance to chlorides. They are also well-suited for structural components, ensuring durability and reliability in various applications.
