Fajar Metals, located in Jakarta, Indonesia, has earned a solid reputation as a manufacturer and supplier of high-performance Duplex Steel Manifold Valves. These valves are expertly designed to control, isolate, and regulate pressure in fluid systems, making them capable of withstanding extreme operating conditions. Crafted from top-quality duplex stainless steel, Fajar Metals’ manifold valves boast remarkable strength, corrosion resistance, and a long lifespan. Catering to essential industries like oil & gas, chemical processing, marine, and power generation, Fajar Metals guarantees that each valve adheres to global quality and safety standards. With precision engineering and sturdy construction, their Duplex Manifold Valves ensure reliable, leak-free operation even in the toughest conditions.
Duplex Steel Manifold Valves are typically made from grades such as UNS S31803 or S32205. Their composition features 21–23% chromium, 4.5–6.5% nickel, 2.5–3.5% molybdenum, nitrogen, and the remainder being iron. The dual-phase (austenitic-ferritic) structure provides impressive mechanical strength and excellent resistance to pitting, crevice corrosion, and stress corrosion cracking. These valves generally have a tensile strength ranging from 620–880 MPa and a yield strength of about 450 MPa. Their ability to endure high pressure and temperature conditions makes them perfect for critical control systems in corrosive and high-stress industrial settings.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| ELEMENT | DUPLEX 31803 | DUPLEX 2205 |
|---|---|---|
| NI | 4.50 – 6.50 | 4.50 – 6.50 |
| C | 0.030 max | 0.030 max |
| N | 0.14 – 0.20 | 0.08 – 0.20 |
| P | 0.030 max | 0.030 max |
| MN | 2.00 max | 2.00 max |
| CR | 22.0 – 23.0 | 21.0 – 23.0 |
| S | 0.020 max | 0.20 max |
| MO | 3.0 – 3.5 | 2.50 – 3.50 |
| SI | 1.00 max | 1.00 max |
| FE | 63.72 min | 63.54 min |
| Grade | % Elongation | YS (MPa) | Hardness(BHN) | UTS (MPa) |
| 31803 | 25 min. | 450 min. | 293 max. | 620 min. |
| 2205 | 25 min. | 450 min. | 293 max. | 655 min. |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Needle Valve in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Steel Manifold Valves find extensive use in instrumentation and process control systems across a variety of industries. In the oil & gas sector, they play a crucial role in pressure monitoring, flow control, and safety shutdown systems on offshore platforms and pipelines. In chemical and petrochemical plants, they manage corrosive fluids in high-pressure applications. The marine industry employs them in ballast systems and seawater handling. Additionally, power generation facilities and desalination plants rely on these valves for their durability and efficiency.
