Fajar Metals, located in Jakarta, Indonesia, stands out as a leading manufacturer and supplier of top-notch Copper Nickel Sheets and Plates. These products are known for their impressive corrosion resistance, durability, and strength, making them perfect for tough industrial applications. Crafted from Cu-Ni alloys like 90/10 (C70600) and 70/30 (C71500), these sheets and plates excel in resisting seawater, brine, and other harsh environments. Commonly found in the marine, petrochemical, and power generation sectors, Fajar Metals ensures that their Copper Nickel offerings meet international quality standards. With strict quality control and prompt delivery, they guarantee the reliability and longevity of every sheet and plate.
Copper Nickel Sheets and Plates are generally composed of Cu-Ni alloys such as 90/10 (C70600) and 70/30 (C71500). The 90/10 alloy is made up of 90% copper and 10% nickel, while the 70/30 alloy contains 70% copper and 30% nickel, along with small amounts of iron and manganese. These alloys are renowned for their outstanding resistance to seawater corrosion, biofouling, and stress corrosion cracking. Their mechanical properties include a tensile strength ranging from 275 to 380 MPa, a yield strength of about 105 to 160 MPa, and good ductility. Additionally, their high thermal conductivity and oxidation resistance make them ideal for high-performance applications in challenging environments.
| Specifications | ASTM B171, B122 / ASME SB171, SB122 |
| Standards | ASTM, ASME and API |
| Size | 1 mm to 100 mm |
| Finishing | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) & Angle, Channel, Tray, Roll Etc. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | UNS NO. C92200 & UNS NO. C83600, UNS NO. C70600 ( CU -NI- 90/10), C71500 ( CU -NI- 70/30), UNS NO C10100, C10200, C10300, C10800, C12000, C12200. |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
|---|---|---|---|---|---|---|
| Cupro Nickel | 88.6 min | 1.0 max | 0.05 max | 9-11 max | 1.8 max | 1 max |
| Element | Copper Nickel 90/10 |
|---|---|
| Density | 8.1 g/cm3 |
| Melting Point | 1443 °C (2430 °F) |
| Tensile Strength | Psi -80,000, MPa -551 |
| Yield Strength (0.2%Offset) | Psi – 35,000, MPa – 241 |
| Elongation | 30 % |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel Sheet and Plates in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel Sheets and Plates find extensive use in industries that demand exceptional corrosion resistance, particularly in marine settings. In shipbuilding, they are crucial for creating seawater piping, heat exchangers, and condenser tubes. Offshore oil platforms rely on these materials for components that face severe marine conditions. They are also utilized in desalination plants, power generation facilities, and the petrochemical sector for their corrosion-resistant properties.
