Fajar Metals, a trusted manufacturer and supplier based in Jakarta, Indonesia, specializes in high-performance AWS Class ERNiFeCr-1 MIG and TIG Filler Welding Wire and Rod, perfect for critical welding tasks. These filler materials are specifically crafted for nickel-iron-chromium alloy base metals, especially those that need to withstand high temperatures and corrosive conditions. Renowned for their outstanding metallurgical integrity and weldability, ERNiFeCr-1 wires and rods find extensive use in the aerospace, power generation, and marine sectors. Fajar Metals offers these filler wires and rods in various diameters and spool sizes, ensuring reliable and precise welding performance for a wide range of demanding projects.
The AWS Class ERNiFeCr-1 welding wire and rod are made from a nickel-iron-chromium alloy base, enhanced with carefully measured amounts of molybdenum, titanium, aluminum, and other elements. This unique blend provides remarkable high-temperature strength, oxidation resistance, and toughness in the weld metal. The alloy excels in creep resistance and maintains its structural integrity even in high-temperature and high-stress environments. ERNiFeCr-1 filler material creates a stable arc, produces a smooth bead appearance, and minimizes porosity, ensuring top-notch weld joints. Fajar Metals guarantees consistent mechanical properties, corrosion resistance, and weldability that meet AWS and industry standards.
| Classification | AWS A5.14, ERNiFeCr-1 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ERNiFeCr-1 MIG & TIG Filler Metal Application & uses |
|
| C | Mn | Si | Cr | S | P | Ni | Fe | Cu | Al | Mo | Ti |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ≤0.05 | ≤1 | ≤0.5 | 19.5-23.5 | ≤0.03 | ≤0.03 | 38-46 | ≥22 | 1.5-3.0 | ≤0.2 | 2.5-3.5 | 0.6-1.2 |
| Tensile Strength MPa(ksi) | Yield Strength MPa(ksi) | Elongation % | |
|---|---|---|---|
| AWS requirement | 550(80) | Not specified | Not specified |
| Typical results as welded | 550(80) | – | 25 |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ERNiFeCr-1 MIG and TIG Filler Welding Wire and Rod in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
AWS class ERNiFeCr-1 MIG and TIG Filler Welding Wire and Rod are widely used in applications requiring durable and corrosion resistant welds. Especially effective for welding nickel, steel, chromium alloys and stainless steel under high temperature and high pressure conditions for building and repairing electrical equipment in general applications, such as turbines and boilers, as well as and chemical industry and marine environments against oxidation and corrosion The ability to join dissimilar metals, which is important also makes it valuable in a variety of complex welding applications.
