Fajar Metals stands out as a reliable manufacturer and supplier of top-notch metal alloys right in Jakarta, Indonesia. We specialize in providing high-quality Aluminium Bronze Sheets and Plates that are perfect for demanding industrial applications. Renowned for their strength, resistance to corrosion, and outstanding wear characteristics, our products are designed to thrive in tough environments like marine, chemical, and aerospace industries. At Fajar Metals, we follow international quality standards and utilize advanced production methods to guarantee precision and material integrity. With a strong focus on reliability, quick delivery, and customer satisfaction, we proudly distribute Aluminium Bronze Sheets and Plates throughout Southeast Asia and beyond.
Aluminium Bronze Sheets and Plates are mainly made up of copper (around 80–90%) and aluminum (5–12%), with small amounts of iron, nickel, and manganese added to boost their strength and resistance to corrosion. These alloys boast impressive tensile strength ranging from 70,000 to 110,000 psi, along with excellent yield strength and remarkable resistance to erosion, cavitation, and corrosion, particularly in seawater and chemical settings. Fajar Metals offers Aluminium Bronze materials in various grades like C61400, C63000, and C95400, all compliant with ASTM B171 and B169, and available in different tempers and finishes to meet the demanding needs of mechanical and structural applications.
| Specifications | ASTM B505 / ASME SB505, BS EN 10088-2, en 10028-7, IS 6911, AMS 4640, UNS C63000, UNS C95800, UZ19AL6, UNS C95510, AMS 4880 |
| Dimensions | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range | Cold Rolled : 0.5-6.4 mm Hot Rolled : 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| International Standard of Sheets | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) | EN 10258/ DIN 59381 EN 10151 EN 10088 |
| Finish | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Alloys | Aluminium | Iron | Nickel | Manganese | Zinc | Arsenic |
| CuAl5 | 4.0–6.5% | 0.5% max. | 0.8% max. | 0.5% max. | 0.5% max. | 0.4% max. |
| CuAl8 | 7.0–9.0% | 0.5% max. | 0.8% max. | 0.5% max. | 0.5% max. | |
| CuAl8Fe3 | 6.5–8.5% | 1.5–3.5% | 1.0% max. | 0.8% max. | 0.5% max. | |
| CuAl9Mn2 | 8.0–10.0% | 1.5% max. | 0.8% max. | 1.5–3.0% | 0.5% max. | |
| CuAl10Fe3 | 8.5–11.0% | 2.0–4.0% | 1.0% max. | 2.0% max. | 0.5% max. | |
| CuAl10Fe5Ni5 | 8.5–11.5% | 2.0–6.0% | 4.0–6.0% | 2.0% max. | 0.5% max. |
| Properties | Metric | Imperial |
| Hardness, Rockwell C | 27 | 27 |
| Tensile strength (M30 and O61 tempers) | 690 MPa | 100000 psi |
| Yield strength (M30 and O61 tempers) | 380 MPa | 55100 psi |
| Elongation at break (in 50 mm, 1% reduction in area) | 1.00% | 1.00% |
| Elastic modulus | 117 GPa | 17000 ksi |
| Compressive yield strength (at permanent set of 0.1%) | 450 MPa | 65300 psi |
| Compressive yield strength (at permanent set of 1%) | 880 MPa | 128000 psi |
| Poisson’s ratio | 0.34 | 0.34 |
| Charpy impact (@ 18.0 – 100°C/ -0.400 – 212°F, keyhole) | 3.00 J | 2.21 ft-lb |
| Izod impact (@ 18.0 – 100°C/ -0.400 – 212°F) | 3.00 J | 2.21 ft-lb |
| Fatigue strength (@# of cycles 1.00e+8, M30 temper) | 460 MPa | 66700 psi |
| Machinability (UNS C36000 (free-cutting brass) = 100) | 20 | 20 |
| Shear modulus | 42.3 GPa | 6140 ksi |
At Fajar Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Aluminium Bronze Sheets and Plates in Jakarta, Indonesia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Indonesia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Aluminium Bronze Sheets and Plates find extensive use in marine hardware, pump and valve components, offshore oil and gas platforms, aerospace parts, and chemical processing equipment. Their exceptional resistance to saltwater, biofouling, and wear makes them perfect for applications like heat exchanger plates, ship propellers, bearing liners, and structural panels that face corrosive or abrasive conditions. In heavy industry, they serve as base plates and wear-resistant surfaces capable of handling high loads and temperatures. Fajar Metals is dedicated to providing Aluminium Bronze Sheets and Plates that meet the highest standards for quality and performance.
